CP100 Downvision Module

General Specifications

• Product Number: E70204
• Compatible with:
• aSeries
• cSeries
• eSeries
• the New eS Series
• gS Series
• Note: Ensure you have the latest software
• Sonar type: CHIRP
• Nominal supply voltage: 12/24V DC Systems
• Operating voltage range: 10.2 - 32 V DC
• Power consumption at full power: 3 watts
• Operating temperature range: 0ºC to +55ºC
• Storage temperature range: -30ºC to +70ºC
• Waterproofing standard: IPX6 and IPX7
• Connections:
• Power (power cable)
• Transducer (9 pin connector)
• Raynet network connector
• Transducer info: Max depth DownVision - 600ft, CHIRP - 600ft.
